Render markdown as a grid grob

Parses a markdown string and returns a grid grob, so plot labels can mix ordinary prose formatting with real LaTeX math. Inline markdown (**bold**, *italic*, `code`, ~~strike~~) is translated to the equivalent LaTeX commands, while $...$ (and \(...\), $$...$$, \[...\]) math spans are passed through to MicroTeX byte-for-byte.

Usage

markdown_grob(md, style = NULL, ...)

grid.markdown(md, ...)

Arguments

md

Character string of markdown.

style

Appearance of the text: a markdown_style object, CSS text, or a path to a .css file. NULL (default) uses latex_options("markdown_style") if set, and the built-in defaults otherwise. Only the properties md_style marks as inline apply here — there is no block layout in a single run for a margin, an indent or an alignment to act on, so those are ignored. markdown_box_grob honours them all.

...

Passed to latex_grob — e.g. x, y, hjust, vjust, rot, max_width, gp.

Value

A latexgrob, as returned by latex_grob.

Details

Markdown and LaTeX disagree about several characters — most importantly \, which CommonMark treats as an escape. Math spans are therefore hidden from the markdown parser before it runs and restored afterwards, so constructs like $\begin{matrix}a\\b\end{matrix}$ survive intact.

That hiding uses three private-use codepoints (U+E000, U+E001, U+E002) as markers, so those three characters are removed from the input. They are unassigned in Unicode, but icon fonts such as Nerd Fonts do put real glyphs there: if your text contains one it will be dropped rather than drawn. The alternative is worse — a pasted marker would be spliced together with a math span on the way back out and silently duplicate a formula.

GFM has no markdown syntax for colour, underline, super/subscript, highlight or size, so — as in CommonMark, and as ggtext does — these come from inline HTML. Each tag renders as HTML's own default rendering prescribes:

tag	effect
<b>, <strong>	bold
<i>, <em>, <cite>, <dfn>, <var>, <address>	italic
<code>, <kbd>, <samp>, <tt>	monospace
<u>, <ins>	underline
<s>, <del>, <strike>	strikethrough
<sub>, <sup>	sub / superscript
<mark>	yellow highlight
<small>, <big>	smaller / larger
<q>	wrapped in quotation marks
<br>	line break
<span style="...">	see below

A style attribute is read for color (any R colour name, the nine CSS names R lacks — crimson, teal, rebeccapurple and friends — #rgb, #rrggbb or rgb(); note that green, gray, grey, maroon and purple keep their R values, not their CSS ones), text-decoration (underline, line-through), font-size (pt, px, in, cm, mm, em, rem, %, smaller, larger) and font-family. Any other property is ignored.

font-family takes the CSS generics monospace, sans-serif and serif, or any font name; a fallback list resolves to its first entry. The name is handed to gp$fontfamily, so the device resolves it: ragg and svglite see any installed family plus anything registered with systemfonts::register_font(), cairo devices see installed families, and base pdf() sees only what pdfFonts() declares — a named family will not resolve there. An unavailable font falls back silently, as it does for gpar(fontfamily=). A font file that is not installed system-wide is used by registering it first:

systemfonts::register_font(name = "MyFont", plain = "MyFont.otf")

load_math_font is not the function for this — it registers math fonts with MicroTeX, which is a different mechanism.

A span's own family wins over gp$fontfamily, but the width of the spaces between its words still comes from gp$fontfamily; set both to the same family if that shows.

Tags nest and combine freely with markdown. Any other tag — and all block-level HTML — is dropped, keeping the text inside it, which is also what a browser shows for the ones (<a>, <abbr>, <span> without a style) that have no default rendering.

Not every markdown feature has a MicroTeX equivalent. Links keep their text and drop the destination, and images keep their alt text.

Everything is flattened into a single run here, with paragraphs joined by line breaks: there is no block layout, so indentation, list markers and block-quote rules need markdown_box_grob. A heading still takes the size and weight its style gives it, since those compile to LaTeX commands rather than to layout.

See also

latex_grob, latex_wrap

Examples

# \donttest{
  grid::grid.newpage()
  grid.markdown("The **fitted** slope is $\\beta_1$, *p* < 0.001")

# }
