Forest plot style

Set the look of a forest plot. Each part of the plot takes a gpar object, and only the settings given are changed, everything else keeps its default. A style can be passed to the theme argument of forest or applied to a plot with set_style, so the same style can be reused for many plots. To change some settings of a plot and keep the rest, give them to set_style instead.

The text itself, such as the title or the legend labels, is set with set_labs.

Usage

forest_style(
  base_size = 12,
  base_family = "",
  parse = NULL,
  ci = gpar(),
  ci_pch = 15,
  ci_t_height = NULL,
  summary = gpar(),
  ref_line = gpar(),
  vline = gpar(),
  xaxis = gpar(),
  xlab = gpar(),
  xlab_adjust = c("refline", "center"),
  title = gpar(),
  title_just = c("left", "right", "center"),
  footnote = gpar(),
  arrow = gpar(),
  arrow_type = c("open", "closed"),
  arrow_length = 0.05,
  arrow_label_just = c("start", "end"),
  legend = gpar(),
  legend_position = c("right", "top", "bottom", "none"),
  legend_ncol = 1,
  legend_byrow = TRUE,
  body = gpar(),
  header = gpar(),
  fit = c("none", "width", "both"),
  ...
)

Arguments

base_size: The size of text.
base_family: The font family, the font of the device by default.
parse: Whether text is read as plotmath expressions, see plotmath. This applies to the title, x-axis labels, footnote, arrow labels and legend labels; text in the table cells is parsed with parse in core and colhead through .... By default only the footnote is parsed, TRUE parses all of them where the text is a valid expression and FALSE parses none.
ci: Confidence intervals, col, fill, lty, lwd and alpha are used. Provide a vector for each group of a grouped forest plot. fill is only used if ci_pch is within 15:25 and alpha must be a single value; a small vertical line marks the point estimate if it is not 1.
ci_pch: Shape of the point estimation, reused for each group if a single value is given.
ci_t_height: The height of the T end of the confidence intervals. No T end is drawn by default.
summary: Diamond shaped summary confidence intervals, col and fill are used.
ref_line: Reference line, its position is set with ref_line of forest.
vline: Vertical lines, their positions are set with vline of set_xaxis. lwd, lty and col can be vectors with one value for each line.
xaxis: X-axis line, tick marks and tick labels.
xlab: X-axis labels.
xlab_adjust: Align the x-axis labels to the reference line "refline" (default) or to the center of the x-axis "center".
title: Title.
title_just: The justification of the title, "left" (default), "right" or "center".
footnote: Footnote.
arrow: Arrows and their labels.
arrow_type: Type of the arrow head, "open" (default) or "closed", see arrow.
arrow_length: The length of the arrow head, a unit or a number in inches. The default is 0.05 inches.
arrow_label_just: Align the arrow labels to the starting point of the arrows "start" (default) or to their ending point "end".
legend: Legend text.
legend_position: Position of the legend, "right" (default), "top", "bottom" or "none" to hide the legend.
legend_ncol: The number of columns of the legend, see legendGrob.
legend_byrow: Whether the rows of the legend are filled first, see legendGrob.
body: Text and background of the body of the table, a short form of core in ...: col, fontsize, fontface, fontfamily, cex, lineheight and alpha are used for the text, fill for the background. A vector is recycled over the rows.
header: Text and background of the header of the table, a short form of colhead in ..., same as body.
fit: How the plot uses the space it is drawn in, for example the size given to ggplot2::ggsave or a panel of patchwork. With "none" (default) the plot keeps its natural size, the size given by get_wh, and is centred in the space. With "width" the CI columns take the free width, in proportion to their natural width, and become narrower when space is short. "both" also shares the free height between the rows of the table. Text always keeps its size.
...: Settings passed on to the theme of the table, see tableGrob: core for the body of the table and colhead for its header, each a list with fg_params for the text and bg_params for the background. For example core = list(fg_params = list(hjust = 1, x = 0.9)) aligns the text of the body to the right. body and header above are applied on top of them, so settings given in both places come from body and header. The border of a cell takes the colour of its fill, so that there is no gap between the cells, unless bg_params of core or colhead gives it a colour.

Value

A forest_style object.

Examples

library(grid)
# Read provided sample example data
dt <- read.csv(system.file("extdata", "example_data.csv", package = "forestploter"))
dt <- dt[1:8, ]

# NA to blank or NA will be transformed to character
dt$Treatment <- ifelse(is.na(dt$Treatment), "", dt$Treatment)
dt$Placebo <- ifelse(is.na(dt$Placebo), "", dt$Placebo)

# Add blank columns for the forest plot to display CI.
# Adjust the column width with space.
dt$` ` <- paste(rep(" ", 20), collapse = " ")
dt$`  ` <- paste(rep(" ", 20), collapse = " ")

# A style that can be reused for other plots
st <- forest_style(base_size = 10,
                   ref_line = gpar(col = "red"),
                   vline = gpar(col = "grey60"),
                   footnote = gpar(col = "#636363", fontface = "italic"),
                   arrow_type = "closed",
                   title_just = "center")

# Add the axis and the text to the plot
p <- forest(dt[, c(1:3, 19)],
            est = dt$est,
            lower = dt$low,
            upper = dt$hi,
            sizes = dt$est,
            ci_column = 4,
            ref_line = 1,
            style = st) |>
  set_xaxis(x_trans = "log",
            xlim = c(0.25, 4),
            ticks_at = c(0.5, 1, 2, 4),
            vline = c(0.5, 2)) |>
  set_labs(title = "Subgroup analysis",
           xlab = "Hazard ratio",
           arrow = c("Placebo Better", "Treatment Better"),
           footnote = "This is the demo data.") |>
  scale_sizes(method = "range", range = c(0.3, 0.8))

plot(p)


# Change the style, let the CI column take the free width of the page and
# remove the footnote
p <- p |>
  set_style(base_size = 12, title = gpar(col = "blue"), fit = "width") |>
  set_labs(footnote = NULL)

plot(p)


# Grouped CIs in two columns, with a legend
p <- forest(dt[, c(1, 19, 20)],
            est = list(dt$est_gp1, dt$est_gp2, dt$est_gp3, dt$est_gp4),
            lower = list(dt$low_gp1, dt$low_gp2, dt$low_gp3, dt$low_gp4),
            upper = list(dt$hi_gp1, dt$hi_gp2, dt$hi_gp3, dt$hi_gp4),
            ci_column = c(2, 3),
            ref_line = 1,
            nudge_y = 0.2,
            style = forest_style(ci = gpar(col = c("#377eb8", "#4daf4a")),
                                 legend_position = "bottom")) |>
  set_xaxis(x_trans = "log", xlim = list(c(0.1, 5), NA)) |>
  set_labs(xlab = c("CVD outcome", "COPD outcome"),
           legend_title = "Group",
           legend_labels = c("Trt 1", "Trt 2"))

plot(p)
