Connect grob box with arrow. — connect

This function is used to create an arrow line to connect two boxes. User should provide the starting and ending side of the arrow.

Usage

connect_box(
  start,
  end,
  connect,
  type = c("s", "p"),
  name = NULL,
  arrow_gp = consort_opt("arrow_gp"),
  arrow_length = consort_opt("arrow_length"),
  arrow_type = consort_opt("arrow_type")
)

Arguments

start: Starting point of the arrow.
end: Ending point of the arrow.
connect: The connection of the box. It should be the combination of the position. The t refers to "top", l for "left", b for "bottom" and r for "right". The first letter is the starting point of the start box, the second is the ending point of the end box. For example, if one wants to connect the left side of the start box with right side of the left side of the end box, the value should be "lr". All the connection will be started in the middle point.
type: Should be one the "s" (strait line), or "p" (polyline).
name: A character identifier of the line grob, passed to linesGrob.
arrow_gp: Graphical parameters gpar object for the connector line. Defaults to grid::gpar(col = "black", lwd = 1).
arrow_length: Length of the arrowhead as a unit object. Defaults to unit(0.1, "inches").
arrow_type: Arrow type, either "closed" or "open". Defaults to "closed".

Value

A lines grob with arrow.

Examples

fg1 <- textbox(text = "This is a test")
fg2 <- textbox(text = "This is an other test", 0.7, 0.2)
grid::grid.draw(fg1)
grid::grid.draw(fg2)

connect_box(fg1, fg2, connect = "bl", type = "p")
#> lines[GRID.lines.59]

# Customize line width and color
connect_box(fg1, fg2, connect = "bl", type = "p", arrow_gp = grid::gpar(lwd = 2, col = "red"))
#> lines[GRID.lines.68]

# Or set globally via set_consort_defaults
set_consort_defaults(arrow_gp = grid::gpar(lwd = 2, col = "blue"))
